  • Detector de agua y cavidad geoeléctrica: Determina la resistencia del suelo a una profundidad de 100 m y visualiza los valores medidos en 2D
  • Profundidad de detección: Con esta tecnología, los clientes encontraron agua hasta 100 m (328 ft) profundo
  • Casos de uso: Detección de agua, detección de cavidades, ingeniería geotécnica
  • Modos de funcionamiento: Exploración geoeléctrica
  • Estructuras detectables: Depósitos de agua, grava con agua, cavidades
EUR 6.490,00
AED 26,738.80 | USD 7,990.00

más IVA, gastos de envío y aduana

+971 50 3426171

Lun - Vie 9 a.m. - 5 p.m. Sábados y Domingos sólo con cita previa

Idiomas: عربي (AR), English (EN), Deutsch (DE)

Otras opciones de contacto »

  • 25
  • 24
  • 23
  • 22
  • 21
  • 20
  • 19
  • 18
  • 17
  • 16
  • 15
  • 14
  • 13
  • 12
  • 11
  • 10
  • 9
  • 8
  • 7
  • 6
  • 5
  • 4
  • 3
  • 2
  • 1

Procedimiento de medición geoeléctrica

Visualización 2D

Manejo multilingüe

Pantalla a color / Pantalla táctil

Memoria interna

Batería recargable de alta capacidad

Water detector and cavity detector down to 100 meters (328 ft) depth

Like the water detector OKM GeoSeeker, the GeoSeeker Mini utilizes a geoelectrical measurement procedure based on Schlumberger. The water detector – that can also be used to detect underground cavities – determines the soil resistivity. Based on that apparent resistivity of the ground the detector is able to detect underground water resources like fresh water, drinking water, water-bearing gravel and groundwater level.

Water detection in Africa
July 04, 2018
Detección de agua en África

GeoSeeker de OKM se utiliza con éxito para detectar agua hasta profundidades de 250 mts en África. El equipo de Mali utiliza el detector de agua con fines humanitarios.

Leer más

Based on the fact that underground water has a very good conductivity, you can conclude that very bad conductivity is a hint for hidden cavities like caves, tunnels, chambers and underground rooms. Thus, the geophysical detector GeoSeeker Mini can be deployed as water finder and cavity detector at the same time.

OKM GeoSeeker Mini

OKM GeoSeeker OKM GeoSeeker

OKM GeoSeeker

Detector de Agua hasta 250 m (820 ft) de Profundidad
OKM Power Pack 3P OKM Power Pack 3P
ePaper OKM Explorer #1 2023

Operating the water and cavity detector GeoSeeker Mini

The water detector GeoSeeker Mini is operated via touchscreen. Select the measurement depth as well as the amount of scanning points and simply follow the graphical instructions. Due to easy-to-understand images and icons, the GeoSeeker Mini is multilingual by using pure picture language.

OKM GeoSeeker Mini
OKM GeoSeeker Mini

During the measurement the electrodes have to be replaced several times to measure the ground resistivity at certain places. All instructions can be read from the color display, where the results are presented after each single scan. At the very end of a measurement the final result is shown as a graphical 2D scan image.

Data visualization of water resources and cavity

After finishing a geoelectrical measurement, the final result is calculated to generate a representative 2D scan image of the underground resistivity. With the pictograms in the lower display area, users can read directly the diagram: The colors in the scheme indicate water deposits (blue with water drops) and/or detected cavities (red with tunnel symbol).

OKM GeoSeeker Mini
GeoSeeker Mini display with selected measuring depth of 20 m: Measurement data show water occurrence (blue) and detected cavity (red) up to 20 m depth.
OKM GeoSeeker Mini
GeoSeeker Mini display with selected measuring depth of 100 m: Measurement data show water occurrence (blue) and detected cavity (red) up to 100 m depth.

Depending on the selection of the size and depth of the measurement, the display contains several columns and is provided with corresponding depth information.

Using the left button (water drops) and the middle button (tunnel entrance), the user can switch to simplified representations of the measurement results.

OKM GeoSeeker Mini
GeoSeeker Mini with simplified indication: The waterfinder has detected a low resistance value in the center of the measuring field, which indicates high conductivity, i.e. water occurrence.
OKM GeoSeeker Mini
GeoSeeker Mini with simplified indication: The detector found a high resistance value in the center of the measuring field, indicating a cavity.
OKM GeoSeeker Mini
GeoSeeker Mini with simplified indication: The buttons can be used to display further measurement results - cavity and 2D diagram.
OKM GeoSeeker Mini
Selection of the screen view: Inactive buttons indicate that no water and/or cavity has been detected. In this case, the 2D diagram is available as an overview of the measurement data.

Thanks to the realization of step-by-step instructions and results in simple images and pictograms, the GeoSeeker Mini is language-independent. That means, the water detector can be used by inexperienced users all over the world – no matter what language they speak.

Geoelectrical applications with GeoSeeker Mini

The geoelectrical detector OKM GeoSeeker Mini can be used to detect underground water resources as well as hidden cavities. Both structures can be located due to its specific characteristics of electrical resistivity.

Water detection

Underground water resources have a good electrical conductivity and measuring its resistivity will result in low apparent resistivity values. The capability of water detection is very useful for

  • dowsers, water finders
  • well builders, drilling companies
  • agriculture, fruit growing
  • mining, building contractors

Detectable subsurface water deposits could be

  • ground water level
  • fresh water, drinking water
  • underground watercourse, water veins
  • underground water streams, headwaters

Cavity detection

Hidden cavities and hollow spaces have a rather poor electrical conductivity and measuring its resistivity will result in high apparent resistivity values. The capability of cavity detection is useful for

  • archaeologists, historians
  • treasure hunters
  • geotechnical engineering
  • military services
  • building contractors

Detectable subsurface cavities could be

  • caves, tunnels
  • galleries and manholes
  • chambers, sepulchers, tombs
  • bunkers, vaults, cellars, rooms
Agriculture
Agriculture
Archaeology
Archaeology
Cavity Detection
Cavity Detection
Geotechnical Engineering
Geotechnical Engineering
Water Detection / Well Building
Water Detection / Well Building
OKM Search Services
OKM Search Services
1xUnidad de control
4xElectrodo
2x2 Tambores para cables de potencia (Ø 290 mm)
2xCable de tensión (10 m)
2xCable de conexión (2 m)
1xPower Pack
1xCargador con cable de carga
1xAdaptador de viaje
1xMaletín impermeable y resistente a los golpes
1xGuía de inicio rápido

Control unit

  • Dimensions (H x W x D): 410 x 340 x 180 mm
  • Weight: 4.5 kg
  • Input voltage (max.): 11 – 13 V DC / 30 W
  • Display: 3.5” Resistive touch, 480 x 320 Pixel
  • Display CPU: Cortex M3, 32 MHz, 128 KB RAM
  • Data memory: 4 GB
  • Sample rate: 4096 Hz (64-fold oversampling of 512 values)
  • Operating time: approx. 6 – 8 h
  • CPU: 80 MHz Cortex M3
  • ADC: 16 bit
  • Effective Range: (differential) –1400 to +1400 mV
  • Measurement Period per Scan Point: min. 16 s
  • Output: 320 V / 0.4 A
  • Input Resistance (static): approx. 12 MΩ

Power Cable Drums (Ø 290 mm)

  • Dimensions (H x W x D): 360 x 290 x 200 mm
  • Weight: 3.6 kg
  • Cable length: 100 m
  • Markers: 10

Electrodes

  • Dimensions (H x W x D): 270 x 120 x 35 mm
  • Weight: 0.4 kg

Voltage Cable

  • Cable length: 10 m
  • Markers: 10
The technical data are average values. Minor deviations are possible during operation.
